Norfield E Series Magnum and 260MX Manual Strike Jamb Router
$77,600
NF10599
Famous for its durability, speed, and versatility, the E Series Magnum rapidly processes 75+ prehung standard doors a day, and is also excellent for custom configurations with infinite adjustability for hinge/lock locations, door height, and door width. The Emag automatically machines the lock bore, latch bore, AND faceplate pocket, all without repositioning the door. The result is faster production and simpler operation. Save even more time with quick change between square and beveled doors, and lock backset. Finally, the standard power-fed door beveller provides even more flexibility.
The 260MX features an extended template holder that allows you to produce both interior and double-prep exterior strikes, without changing templates or repositioning the jamb. It’s also ideal for ball catch head jambs: simply insert the ball catch template and use the included stops for precise spacing and location.
Both machines have been safely stored for 3 years and will require a tune up once installed. Available for immediate shipment.
When purchasing any used machine, consult your doorshop sales person about OEM technical support.
Features
- Automatic face plate routing
- Quick change backset
- Quick change 3-1/2 degree hinge mortise
- Bolt on wear surfaces
- Machine doors from 4' to 9' tall and from 1' to 4' wide
- Raised molding compatible
- One 8' (for doors up to 8') and one 9' integrated stop systems for quick change between pre-set hinge patterns
- Partial lock boring for door pulls
- Pneumatic jamb lift adjustment to ensure a perfect fit
- Insert cutters for low cost cutting blade replacement
- Self-centering butt router for easy hinge mortising
- 3.5° beveler/sizer
- Variable speed power feed allows for soft and hardwood doors
- Infinite door width adjustment
- Power feed wheel bypass
Specs
| Capabilities | Min | Max |
| Door Width | 1'0" | 4'0" |
| Door Height | 4'0" | 9'0" |
| Door Thickness | 1-3/8" | 2-1/4" |
| Jamb Width | 2-1/2" | 10-1/2" |
| Jamb Thickness | 1/2" | 1-5/8" |
| Hinge Size | 3-1/2" | 5" |
| Hinge Radius | 1/4" | 5/8" |
| Lock Backsets | 2-3/8" | 2-3/4" |
| Faceplate Router | up to | 1-1/4" x 2-3/4" |
| Infeed Height | 16" | 20" |
| Outfeed Height | 16" | 20" |
| Approx. Shipping Weight | 4000 lbs | |
| Floor Space | 5'W x 18'L | |
| Electrical | 230V 3 Ph@30 Amps 220V 1 Ph@30 Amps |
|
| Air | 2.2 CFM @ 90 PSI 8.5 CFM @ 90 PSI for manual screwdriver 10 CFM @ 90 PSI for auto screwfeeder or pre-drill |
|
NF10599
Data sheet
- Model
- E Series Magnum and 260MX Manual Strike Jamb Router
- Manufactured Date
- 2023
- Brand
- Norfield
- Price
- $77,600
- Listing Number
- NF10599
- Serial number
- DJ3306E/SR3453MX
- FOB
- CA
