Norfield 4000 Automatic Prehung Door Line
$51,478
NF10557C
The 4000 is a prehung door workhorse. Produce a finished 80” prehung door every 90-120 seconds; 50-250 doors/day is typical. This complete system includes the 4200 Door Loader, 4000 Automatic Prehung Door Machine, and [current style] 540 Automatic Door Frame Assembly Machine. This system was reconditioned by Norfield and carries a 90-day parts warranty. Excellent support available from Norfield. Available in 6 weeks.
When purchasing any used machine, consult your doorshop sales person about OEM technical support.
Features
- Bottom-up clamping system, which accommodates both interior and exterior doors
- Underside lock drilling enables exit cut viewing for quality control
- Superior dust collecting system
- Chip breaker to achieve crisp clean hinge mortising
- Automatic lock, latch and faceplate machining
- Industrial-grade material and parts for longevity
Specs
| Capabilities | Min | Max |
| Door Width | 1’6” | 3’6” |
| Door Height | 6'6" | 7'0" |
| Door Thickness | 1-3/8" | 1-3/4" |
| Jamb Width | 2-1/2" | 10-1/2" |
| Jamb Height | 6'6" | 7'0" |
| Jamb Thickness | 1/2" | 1-1/2" |
| Hinge Size | 3-1/2" | 4" std |
| Hinge Radius | - | 5/8" only |
| Lock Backsets | 2-3/8" | 2-3/4" |
| Faceplate Width | 1-1/8" x 2-3/4" | |
| Approx. Shipping Weight | 3,000 lbs | |
| Floor Space | 6'6"W x 9'L x 6' H | |
| Electrical | 230V 1 PH 208/230V 3PH |
|
| Air | 15CFM @ 90PSI | |
NF10557C
Data sheet
- Model
- 4000
- Manufactured Date
- 2015
- Brand
- Norfield
- Price
- $51,478
- Listing Number
- NF10557C
- Serial number
- MC4120, AS8049, LM4312
- FOB
- CA
