Kval Handler Automatic Door Loader
KV10076
Speed up production and reduce injuries with the Kval Handler. This gantry-style machine automatically picks the top door from a door stack (up to 60 interiors), then places the door on a conveyor table for infeed to a horizontal door machine or lite cutter. Since the door machine (or lite cutter) operator stays at his station while doors come to him/her, tack time is reduced, resulting in higher output. And of course the Handler eliminates manual lifting and the associated safety risks. Available for immediate sale.
When purchasing any used machine, consult your doorshop sales person about OEM technical support.
Door Feeder Door Machine accommodates flush or panel doors up to 3’0” × 8’0” with a maximum weight of 125 lbs., lifting them from a stack (maximum 7’ high) and automatically feeding them to the next machine.
Doors are lifted and held in place by air pressure clamps from both edges of the door, then moved automatically on a track system over the powered roll table, and finally lowered to be processed by the next machine in the line. Cycle time is 40 seconds.
General Specifications
Footprint 8' × 10'
Weight 2,000 lbs.
Height 120" from floor to top of horizontal tube
Data sheet
- Model
- Handler
- Manufactured Date
- 2005
- Brand
- Kval
- Price
- $25,600
- Listing Number
- KV10076
- Serial number
- 05-20-342
- FOB
- VA
